NVT Phybridge NV-216A-PV PVD Power Supply Passive Receiver

NVT Phybridge NV-216A-PV PVD Power Supply Passive Receiver
Images for general purposes only. Actual may be different than depicted.
NVT Phybridge NV-216A-PV PVD Power Supply Passive Receiver

NVT Phybridge NV-216A-PV PVD Power Supply Passive Receiver

SKU: NV-216A-PV
Call (888) 922-5200 for stock
Rating:
$52.95 /ea
0
$0.00
0
$0.00
0

The NV-216A-PV from NVT Phybridge is a Power-Video Transceiver that allows the transmission of real-time monochrome or color video over Unshielded Twisted-Pair (UTP) telephone wire and supports any type of Baseband Signals. The NV-216A-PV from NVT Phybridge allows incorporates the transceiver engine of NVT Phybridge‘s popular NV-214A-M video transceiver with the added value of camera power connections and also Connect the RJ45 to 4-pair cable to be routed to the NVT Phybridge cable integrator and on to an active or passive receiver hub in the MDF/Control Room. The NV-216A-PV allows transmission of CCTV video and low voltage power over UTP cable and has a compact body.

NVT Phyrbidge NV-216A-PV Features:

  • Power-Video (PV) signals are routed via UTP and RJ45
  • Use with NVT Phyrbidge’s PVDTM
  • Power Supply Hubs and Cable Integrators, or with a second NV-216A-PV
  • Up to 750ft (225m) with a NVT Phybridge Passive Hub or Transceiver
  • Up to1,500ft (460m) with a NVT Phybridge StubEQTM Hub
  • Up to 3,000ft (1km) with a NVT Phybridge DigitalEQTM Hub or active receiver, (see Power Distance Chart)
  • Frequency response DC to 10MHz (see Resolution Distance Chart)
  • Supports “up-the-coax” type control signal up to 750ft (225m)
  • Exceptional interference rejection
  • Built-in transient protection

Following are the Attached files for this product:

NVT Phybridge NV-216A-PV PVD Power Supply Passive Receiver Brochure
